Pynamic SINGLE PWM Limiter – 1 Slot
AUD$720.00
LINK STEREO PAIRS
Features
-Link Stereo units together from the front panel
-New LED VU meter
-Original Ratio & Release settings on stepped switches
-Pro audio quality Input and Output Permalloy transformers
-Built with the highest quality discrete components, NO ICs!
-High Pass filter added to sidechain to extend versatility (80Hz)
-Handmade original inductors for the PWM compression circuit
-Provides the full voltage of the original circuit
-Faithful recreation of the original
The Sound
Original PYEs were renowned for their rich, gluey sound making them perfect for mixing anything from guitars to snares to bass.
The Pulse Width Modulation compression type is quite rare and is very unique sounding.
It behaves like thinning scissors, removing material from the waveform at 250 kHz intervals based on the ratio and release settings. It can go from very usable aggressive pumping compression to light transient shaving all very transparently.
It shines particularly on Toms, Drum Bus, Acoustic guitars & Piano (its our go to on acoustic guitar and toms)
Not a VCA, FET, diode or VariMu, the Pynamic is the perfect addition to your dynamics options!
DEMO VIDEOS
Tech Specs
-Ratios: 1:1 , 2:1 , 3:1 , 5:1 , 20:1 (limiter)
-Comp Attack: < 0.5ms original speed (fast) up to 50ms (slow)
-Limiter Attack: 1ms original speed (fast) up to 100ms (slow)
-Release: 100ms, 200ms, 400ms, 800ms, 1600ms, 3200ms
-Sidechain High Pass Filter: 80Hz
-Bypass switch: True Bypass
-Noise Floor: -80dB
-Distortion: < 1% @ 30hz, 100hz, 1k, 10k
-Max Current : +16VDC @ 95mA / -16VDC @ 95mA
These units are MONO
